Standard Model Offset Printing Machine

Next > >

Send Inquiry

Product Code : LOC-1828

Brand Name : LITTLEBERG

Price And Quantity

Minimum Order Quantity
1 Piece
Price
750000 INR

Price Range
750000.00 - 1250000.00 INR

Product Description

Standard Model Offset Printing Machine

Holding years of experience and knowledge in this industry, our company has been able to mark its strong presence in the market as one of the excellent manufacturers & suppliers of Standard Model Offset Printing Machine. We source tested quality metals from reckoned vendors to manufacture these printing machines in compliance with industrial standards. Popular in the market due to their motorized feeder pile table, photocell & double sheet detector and excellent durability, Standard Model Offset Printing Machine is used in various industries for the purpose of printing.

Key Points:

Best quality printing
Durability
At pocket friendly price
Less maintenance

Technical Specifications:

Descriptions	LOC-1620 SWING GRIPPER	LOC-1928 SWING GRIPPER	LOC 1828 STANDARD	LOC 2030 STANDARD	LOC 2232 STANDARD
Sheet Size (max.)	15.5" x 20.5"	19" x 29"	18" x 28"	20" x 30"	22" x 32"
Sheet Size (min.)	7" x 7"	9" x 11"	9" x 11"	12" x 14"	12" x 14"
Printing Area	15" x 20"	18.5" x 28"	17.5" x 28"	19.5" x 30"	21" x 31"
Stock Thickness	30-350 Gsm	30-350 Gsm	30-400 Gsm	30-400 Gsm	30-400 Gsm
Blanket Size	21" x 21"	24" x 31"	22" x 29"	24" x 31"	26" x 32"
Plate Size	17" x 21"	21" x 29"	20" x 29"	22" x 31"	24" x 33"
Plate Thickness	0.29 mm	0.29 mm	0.29 mm	0.29 mm	0.29 mm
Gripper Margin on Plate	1.25" / 1.5"	1.25" / 1.5"	1.25" / 1.5"	1.25" / 1.5"	1.25" / 1.5"
Gripper Margin on Paper	9 mm	9 mm	9 mm	9 mm	9 mm
Inking Unit	20 Ink Rollers	20 Ink Rollers	20 Ink Rollers	20 Ink Rollers	20 Ink Rollers
Dampening Unit	5 Rollers	5 Rollers	5 Rollers	5 Rollers	5 Rollers
Feeding Pile Height	30"	35"	35"	35"	35"
Delivery Pile Height	16"	20"	16"	20"	20"
Printing Speed I.P.H.	7000	6000	5000	5000	4000
Power Required	415 - 440 AC	415 - 440 AC	415 - 440 AC	415 - 440 AC	415 - 440 AC
Main Drive Motor	2 H.P.	3 H.P.	3 H.P.	3 H.P.	5 H.P.
Compressor Pump Motor	2 H.P.	2 H.P.	2 H.P.	2 H.P.	2 H.P.
Floor Space (LxWxH)	66" x 42" x 60"	97" x 59" x 67"	76" x 53" x60	84" x 56" x67"	89" x 57" x 72"
Weight (Approx.)	2000 Kgs.	2500 Kgs.	2500 Kgs.	2800 Kgs.	3300 Kgs.
